"model does not match nx4827t043r"

5 Posts
2 Users
0 Reactions
2,054 Views
(@dahliin)
Active Member
Joined: 5 years ago
Posts: 5
Topic starter

Hello,



i just bought a nextion dash and when i try to upload a HMI with the nextion editor I get the message "model does not match nx4827t043r" on the screen. Any solution?



Quote
(@admin5435)
Prominent Member Admin
Joined: 7 years ago
Posts: 732


Hi !

It's simply because the template have been designed for another model, as long as the size/resolution you simply need to select the correct model in the designer :

1- Clock on "Device" in the toolbar
2- Select the device tab in the window
3- Pick the exact model you own

Then you can recompile and upload using the procedure described on the wiki.



ReplyQuote
(@dahliin)
Active Member
Joined: 5 years ago
Posts: 5
Topic starter

@admin5435

I can't find my my exact modell in the list. NX4827t043R, I can only find one without the R.

This post was modified 4 years ago by dahliin


ReplyQuote
(@admin5435)
Prominent Member Admin
Joined: 7 years ago
Posts: 732


You can use the model without the R, the last R or N tells if it's a resistive touchscreen (R) or no touch (N) : https://nextion.tech/datasheets/nx4827t043/#



ReplyQuote
(@dahliin)
Active Member
Joined: 5 years ago
Posts: 5
Topic starter
Posted by: @admin5435

You can use the model without the R, the last R or N tells if it's a resistive touchscreen (R) or no touch (N) : https://nextion.tech/datasheets/nx4827t043/#

Get this message when I select the right one.



ReplyQuote
